6146/6156 DC Voltage/Current Generators Operation Manual
4.2.4 Operations in Sweep Source Mode
4-9
4.2.4 Operations in Sweep Source Mode
The sweep source mode generates sweep waveforms of DC voltage or DC current.
The source value is swept between the designated start value and stop value with step value stare case
wave.
The following table shows operations in the sweep source mode.
Table 4-5 Operations in Sweep Source Mode
Operational
condition
Scan Mode Description Operation Remarks
Operate ON
Repeat Sweeps the
source value
repeatedly at
intervals
specified by
the step time.
Tp:
Step time
Td:
READY out-
put delay time
Tcn:
Operate pro-
cessing time
Single Sweeps the
source value
at intervals
specified by
the step time.
Hold Sweeps the
source value
by trigger
input.
TRIGGER IN
SYNC OUT
READY OUT
Start trigger Hold trigger Hold release trigger
Output
Standby
Stored value
of the last
number
Operate
Stored value
of the first
number
TRIGGER IN
SYNC OUT
READY OUT
Start trigger
Output
Stop value
Bias value
Start
value
Stays at the
stop value
Returns to the
bias value
Outputs only
in RTB ON
Standby
Operate
Hold trigger Hold release trigger
TRIGGER IN
SYNC OUT
READY OUT
Step trigger
Output
Start
value
Bias value
Start
value
Returns to the
bias value
Outputs only
in RTB ON
Stays at the
stop value
Stop value
Standby
Operate
