6146/6156 DC Voltage/Current Generators Operation Manual
4.2.3 Operations in Memory Recall Mode
4-8
NOTE: If the scan in which voltage source and current source are mixed is executed, the output status will be
set to Standby at switching between functions. However, it will be kept Operate at switching between volt-
age source and thermal electromotive force source.
Source
value
changing
including
range
changing
Single/
Repeat
Scans the
data
repeatedly at
intervals
specified by
the step time.
Tp:
Step time
Td:
READY output
delay time
Tcn:
Operate pro-
cessing time
Trc:
Range change
processing time
Hold
Scans the
data one by
one by
trigger input.
Table 4-4 Operations in Memory Recall Mode (3 of 3)
Operational
condition
Scan Mode Description Operation Remarks
TRIGGER IN
SYNC OUT
READY OUT
Output
Stored value
of the first
number
Sets the source value
Changes the range
*1
If Trc+Td is longer
than the setting Tp,
the actual Tp will be
extended.
TRIGGER IN
SYNC OUT
READY OUT
Output
Stored value
of the first
number
Sets the source value
Changes the range
