6146/6156 DC Voltage/Current Generators Operation Manual
7.2.5 Calibration by Manual Operation
7-12
7.2.5 Calibration by Manual Operation
The calibration procedure by manual operation is shown below
Figure 7-9 Manual Calibration Procedure
No
Yes
Entering calibration mode
Initialize
calibration
data?
Calibration data
initialization
Calibration function
setting
Calibration range
setting
Polarity setting
ZERO point calibration
Full Scale calibration
No
Yes
Calibrating
another range
No
Yes
Calibrating the
other polarity
No
Yes
Calibrating
another function
Calibration data save
Exiting calibration
mode
