ADCMT 6146 User Manual

6146/6156 DC Voltage/Current Generators Operation Manual
8.1 Voltage/Current Source
8-3
• 6156
Thermal electromotive force source range
Room temperature setting range:
-25°C to +85°C
For thermocouple type B, the room temperature of less than 0°C is deemed to be 0°C.
Standard setting: JIS C1602-1995 or JIS C1602-1981
For type N, JIS C1602-1995 is applied.
Thermal electromotive force overall accuracy
Thermocouple Source range Setting resolution
T (CC) -200.0°C to +400.0°C0.1°C
J (IC) -200.0°C to +1200.0°C0.1°C
E (CRC) -200.0°C to +1000.0°C0.1°C
K (CA) -200.0°C to +1372.0°C0.1°C
S (PR10) -10.0°C to +1768.0°C0.1°C
R (PR13) -10.0°C to +1768.0°C0.1°C
B (PR30) +330.0°C to +1820.0°C0.1°C
N -200.0°C to +1300.0°C0.1°C
Thermocouple
(a) - (b)
(a) Source temperature
(b) setting room temperature
Accuracy
Range ± (% of setting +°C)
T (CC) -200.0 °C to +400.0 °C -200.0 °C to -120.1 °C 0.034 + 0.5 °C
-120.0 °C to -50.1 °C 0.025 + 0.3 °C
-50.0 °C to +400.0 °C 0.02 + 0.2 °C
J (IC) -200.0 °C to +1200.0 °C -200.0 °C to -150.1 °C 0.035 + 0.6 °C
-150.0 °C to -50.1 °C 0.025 + 0.5 °C
-50.0 °C to +1200.0 °C 0.02 + 0.4 °C
E (CRC) -200.0 °C to +1000.0 °C -200.0 °C to -150.1 °C 0.035 + 0.5 °C
-150.0 °C to -50.1 °C 0.026 + 0.4 °C
-50.0 °C to +1000.0 °C 0.02 + 0.3 °C
K (CA) -200.0 °C to +1372.0 °C -200.0 °C to -150.1 °C 0.037 + 0.7 °C
-150.0 °C to -50.1 °C 0.026 +0.6 °C
-50.0 °C to +1100.0 °C 0.02 + 0.4 °C
+1100.1 °C to +1372.0 °C 0.023 + 0.4 °C
S (PR10) -10.0 °C to +1768.0 °C-10.0 °C to +550.0 °C 0.02 + 1 °C
+550. 1°C to +1768.0 °C 0.02 + 0.6 °C
R (PR13) -10.0 °C to +1768.0 °C-10.0 °C to +300.0 °C 0.02 + 0.7 °C
+300.1 °C to +1768.0 °C 0.02 + 0.6 °C
B (PR30) +330.0 °C to +1820.0 °C +330.0 °C to +1000.0 °C 0.02 + 1.5 °C
+1000.1 °C to +1820.0 °C 0.02 + 0.7 °C
N -200.0 °C to +1300.0 °C -200.0 °C to -130.1 °C 0.04 + 1 °C
-130.0 °C to -50.1 °C 0.025 + 0.7 °C
-50.0 °C to +1300.0 °C 0.02 + 0.5 °C
