6146/6156 DC Voltage/Current Generators Operation Manual
A.3.2 Internal Processing Time (Typical Value)
A-8
A.3.2 Internal Processing Time (Typical Value)
1. Source processing time
For the time from when the source value changes to when the source value settles, refer to Section
4.2.8, "Settling Time."
Time until the source value changes after Operate input
Program mode Trigger Function
Execution
time
(ms)
DC
Memory
Sweep
(No range change)
External Operate IN Voltage 30 mV range 30
300 mV range 30
3 V range 37
30 V range 38
Current 3 mA range 26
30 mA range 39
200 mA range 39
Thermal electro-
motive force
30
OPR command
(GPIB/USB)
Voltage 30 mV range 30
300 mV range 30
3 V range 40
30 V range 40
Current 3 mA range 26
30 mA range 39
200 mA range 42
Thermal electro-
motive force
30
