3 ARK-6310 User Manual
Chapter 1 General Information
1.3 Specifications of Three ARK-6310 Models
1.3.1 ARK-6310-3M01E
Environment
Operating Temp. 0 ~ 40°C (32 ~ 104°F)
Non-operating Temp. -20 ~ 60°C (-4 ~ 140°F)
Operating Humidity 10 ~ 85% @ 40°C, non-condensing
Non-operating Humidity 10 ~ 95% @ 40°C, non-condensing
Operating Vibration 1 Grms
Non-operating Vibration 2 G
Altitude 0 to 3,048 m (0 ~ 10,000 ft)
Physical
Characteristics
Dimensions (W x H x D) 232 x 65 x 232 mm (9.1” x 2.6” x 9.1”)
Net Weight 2.74 kg (6.03 lb)
Table 1.1: General Features of ARK-6310
Table 1.2: Specifications of ARK-6310-3M01E
Computing System
CPU Intel® LV Pentium® M 1.4 GHz
Front Side Bus 400 MHz
L2 Cache 2 MB
Chipset Intel® 855GME + ICH4
BIOS Award 4 Mbit FWH
Memory
Technology DDR 266/333 SDRAM (ECC/Non-ECC support)
Max. Capacity 1 GB
Graphic
Chipset
Intel® 855GME GMCH integrated Extreme
Graphics 2 controller
Display Memory
Intel® DVMT 2.1 supports up to 64 MB video
memory
Resolution 1600 x 1200 @ 32 bpp (85 Hz)
LVDS
(Optional), Single-channel 18-bit/Dual-channel
36-bit LVDS
DVI
(Optional), Chrontel® CH7009A DVI transmitter
up to 135M pixels/second
TV-Out
(Optional), Chrontel® CH7009A TV encoder sup-
ports both NTSC/PAL
Supports both S-Video and composite video
Dual Display
(Optional), CRT + LVDS, or DVI/TV-out + LVDS
or CRT + DVI
Ethernet
Interface 10/100/1000Base-T
Controller Realtek RTL8110S Gigabit LAN (PCI)
Connector 1 x RJ45
Watchdog Timer
Output System reset
Interval Programmable 1 ~ 255 sec.
Expansion Slot Mini-PCI 1 x 32-bit/33 MHz slot (bottom cover access)
I/O Interface
Front I/O Ports
2 x PS/2 (Mouse & Keyboard), 1 x LPT,
1 x COM, 1 x VGA, 3 x Audio (Mic-in, Line-in,
Line-out), 1 x LAN, 2 x USB
Extra Cutouts
2 x COM, 1 x DVI/LVDS, 1 x S/C-Video,
1 x WLAN Antenna
