ARK-6310 User Manual 44
4.5.1.2 IDE Adapter Setup
The IDE adapters control the hard disk drive. Use a separate sub menu to configure
each hard disk drive. The below table shows the IDE primary master sub menu.
Boot Display CRT
LFP (LVDS)
CRT+LFP(LVDS)
EFP(PANEL-LINK)
TV
CRT+EFP
Select Display Device that the
screen will be shown
Panel Type 640 x 480 18
800 x 600 18
1024 x 768 18
1280 x 1024 24/2
1400 x 1050 24
1600 x 1200 24
1280 x 768 24
1680 x 1050 24
1920 x 1200 24
1024 x 768 24
1024 x 768 18/2
1024 x 768 24/2
1280 x 800 18
1280 x 600 18
Select Panel Resolution that will
be displayed depending on the
LCD Panel (LFP)
TV Standard Off, NTSC
PAL, SECAM
Select the output mode of TV
Standard
Video Connector Automatic, Composite Com-
ponent, Both
Select the type of Video display
connector
TV Format Auto, NTSC_M, NTSC_M_J,
NTSC_433, NTSC_N,
PAL_B, PAL_G, PAL_D,
PAL_H, PAL_I, PAL_M,
PAL_N, PAL_60, SECAM_L,
SECAM_L1, SECAM_B,
SECAM_D, SECAM_G,
SECAM_H, SECAM_K,
SECAM_K1
This item allows you to select dif-
ferent TV signal format when the
TV Standard item is not off.
Table 4.2: Main Menu Selection
Table 4.3: IDE Adapter Setup
Item Options Description
IDE HDD Auto-detection Press Enter Press Enter to auto-detect the HDD on this
channel. If detection is successful, it fills the
remaining fields on this menu.
IDE Primary Master IDE
Primary Slave,
IDE Secondary Master, IDE
Secondary Slave
None
Auto
Manual
Selecting 'manual' lets you set the remain-
ing fields on this screen. Selects the type of
fixed disk. "User Type" will let you select
the number of cylinders, heads, etc. Note:
PRECOMP=65535 means NONE!
Access Mode CHS, LBA
Large, Auto
Choose the access mode for this hard disk
The following options are selectable only if the 'IDE Channel' item is set to 'Manual'
Cylinder Min = 0
Max = 65535
Set the number of cylinders for this hard
disk.
To Next Page
