25 ARK-6130 User Manual
Chapter 2 System Setup and Maintenance
2.7.10 LVDS Connector (JLVDS1 on ARK-6310-3M01E/02E)
Signal Description - LVDS Connector (JLVDS1)
Table 2.11: LVDS Connector (JLVDS1 on ARK-6310-3M01E/02E)
Signal PIN PIN Signal
+5V 2 1 +3.3V
+5V 4 3 +3.3V
I2C_DAT 6 5 I2C_CLK
GND 8 7 GND
Txout0 10 9 Txout1
Txout0# 12 11 Txout1#
GND 14 13 GND
Txout2 16 15 Txout3
Txout2# 18 17 Txout3#
GND 20 19 GND
E_Txout0 22 21 E_Txout1
E_Txout0# 24 23 E_Txout1#
GND 26 25 GND
E_Txout2 28 27 E_Txout3
E_Txout2# 30 29 E_Txout3#
GND 32 31 GND
Txclk 34 33 E_Txclk
Txclk# 36 35 E_Txclk#
GND 38 37 GND
+12V 40 39 +12V
Table 2.12: Signal Description - LVDS Connector (JLVDS1)
Signal Signal Description
I2C_DAT, I2C_CLK I2C interface for panel parameter EEPROM. This EERPOM is
mounted on the LVDS receiver. The data in the EEPROM allows the
EXT module to automatically set the proper timing parameters for a
specific LCD panel.
