Advantech ARK-6310 User Manual

11 ARK-6130 User Manual
Chapter 2 System Setup and Maintenance
2.4 Computing Core Overview
2.4.1 ARK-6310-3M01E/02E Board Placement
Please refer to Section 2.6 for detailed connector placement illustration.
Figure 2.5 ARK-6310-3M01E/02E Board Placement
JCOM2
(Reserved)
LAN
USB0,1
Line_In
Line_Out
Mic_In
JCOM1
(Reserved)
Parallel
COM1
VGA
JP1
JP2
JP3
PS/2 KB
PS/2 Mouse
JFP1
DIMM1
ATX
POWER1
JTMDS1
(Reserved)
JLVDS1
(Reserved)
(Reserved)
JTV1
CF1
(Rear side)
IDE1
IDE2
MPCI1
JBAT1
