1.3.2 ARK-6310-3M02E
Table 1.3: Specifications of ARK-6310-3M02E
Computing System
CPU Intel® ULV Celeron® 600 MHz
Front Side Bus 400 MHz
L2 Cache 512 KB
Chipset Intel® 852GM + ICH4
BIOS Award 4 Mbit FWH
Memory
Technology DDR 200/266 SDRAM (ECC/Non-ECC support)
Max. Capacity 1 GB
Graphic
Chipset
Intel® 852GM GMCH integrated Extreme Graph-
ics 2 controller
Display Memory
Intel® DVMT 2.1 supports up to 64 MB video
memory
Resolution 1600 x 1200 @ 32 bpp (85 Hz)
LVDS
(Optional), Single-channel 18-bit/Dual-channel
36-bit LVDS
DVI
(Optional), Chrontel® CH7009A DVI transmitter
up to 135M pixels/second
TV-Out
(Optional), Chrontel® CH7009A TV encoder sup-
ports both NTSC/PAL
Supports both S-Video and composite video
Dual Display
(Optional), CRT + LVDS, or DVI/TV-out + LVDS or
CRT + DVI
Ethernet
Interface 10/100/1000Base-T
Controller Realtek RTL8110S Gigabit LAN (PCI)
Connector 1 x RJ45
Watchdog Timer
Output System reset
Interval Programmable 1 ~ 255 sec.
Expansion Slot Mini-PCI 1 x 32-bit/33 MHz slot (bottom cover access)
I/O Interface
Front I/O Ports
2 x PS/2 (Mouse & Keyboard), 1 x LPT,
1 x COM, 1 x VGA, 3 x Audio (Mic-in, Line-in,
Line-out), 1 x LAN, 2 x USB
Extra Cutouts
2 x COM, 1 x DVI/LVDS, 1 x S/C-Video,
1 x WLAN Antenna
