ARK-6310 User Manual 28
2.8 Installing the Disk Drive
ARK-6310 supports one 2.5” disk drive. To install:
1. Screw the 2.5” drive into the drive bay bracket.
Figure 2.11 Installing the disk drive in the bay
Note! T
he specific screws and rubbers for 2.5" disk drive are in the accessory
box
4 special screws with
rubber for 2.5" HDD
2.5” HDD
