Advantech ARK-6310 - ARK-6310 Internal Connector List

17 ARK-6130 User Manual
Chapter 2 System Setup and Maintenance
2.6.3 ARK-6310 Internal Connector List
Table 2.3: Internal Connectors
ARK-6310-3M01E/02E ARK-6310-6M01E Function
ATXPWR1 ATXPWR1 ATX power connector
CF1 CF1 Compact Flash socket
CN5 -
4/5/8-wire touch screen connector
(optional)
DIMM1 - 184-pin DDR SDRAM DIMM socket
IDE_1 IDE1 Primary IDE connector
IDE_2 - Secondary IDE connector
JCOM1/2 COM3/4 Serial port connector
JFP1 FPIO1 Front panel connector
JLVDS1 JLVDS1 TMDS LVDS connector
JTMDS1 - TMDS DVI connector
JTV1 - TV-out connector
USB 3 ~ 5 USB connectors
MPCI1 - Mini PCI slot
- SATA 1 ~ 3 Serial ATA connectors
- SO-DIMM1/2 200-pin SODIMM sockets
Note! Please refer to page 13 (for ARK-6310-3M01E/02E) and page 14 (for
ARK-6310-6M01E), to find out each jumper/connector location.
