Advantech ARK-6310 User Manual

ARK-6310 User Manual 22
2.7.6 Secondary IDE Connector (IDE_2 on ARK-6310-3M01E/02E)
Table 2.6: Secondary IDE Connector (IDE_2 on ARK-6310-3M01E/02E)
Signal PIN PIN Signal
RESET# 1 2 GND
SDD7 3 4 SDD8
SDD6 5 6 SDD9
SDD5 7 8 SDD10
SDD4 9 10 SDD11
SDD3 11 12 SDD12
SDD2 13 14 SDD13
SDD1 15 16 SDD14
SDD0 17 18 SDD15
GND 19 20 NC
SDREQ 21 22 GND
SDIOW# 23 24 GND
SDIOR# 25 26 GND
SIORDY 27 28 GND
SDDACK# 29 30 GND
IRQ15 31 32 NC
SDA1 33 34 SATADET
SDA0 35 36 SDA2
SDCS1# 37 38 SDCS3#
IDEACTP# 39 40 GND
+5V 41 42 +5V
GND 43 44 NC
Caution!
Due to IDE compatibility issue, do not use CF and IDE device on sec-
ondary IDE channel at the same time.
