Afinia L901 - Media Detection and Sensor Adjustment

72 Troubleshooting
Afinia
Mis‐registrationor
labelsareskipped
Mediasettingsdonotmatch
themedialoadedintheprinter.
Makesurethesettingsarecorrectforthemedia
(e.g.mediasizeandorientation).
Themediadoesnotmeetthe
specifications.
SeeChoosingLabelMediaonpage24forthe
mediaspecifications.
Theprinterisunable
to
correctlydetecttheinter‐label
gaporblackmark.
1. Cleanthesensors.SeeCleaningtheSensors
onpage58.
2. Iftheproblempers ists,adjustthesensitivity
ofthesensors.SeeAdjustingSensor
Sensitivityonpage77.
Labelsareskipped
whenprintingrollto
rollonmediawithbl ack
mark
Theprinterisunableto
correctlydetecttheinter‐label
blackmark.
Adjustthemediasizeintheprinterdriver:
reducetheheightby0.1”(3mm).
Problem PossibleCause Solution
