Agilent Technologies 1100 Series - Nano Flow Cells

162 1100 Series DAD and MWD User Manual
9 Parts and Materials for Maintenance
Nano Flow Cells
The following kits are available:
Figure 75 shows all parts delivered with the nano-flow cell kits.
Table 25 Nano-flow cell kits
Description Part number
500 nl Flow Cell Kit
includes Flow cell assembly (10 mm, 500 nl, 5 MPa) completely
assembled (includes items 1, 2, 3, 4, 10, 11, 12, 13, 14, 15, and 16)
G1315-68724
80 nl Flow Cell Kit
includes Flow cell assembly (10 mm, 80 nl, 5 MPa) completely assembled
(includes items 1, 2, 3, 4, 10, 11, 12, 13, 14, 15, and 16)
G1315-68716
Figure 75 Content of kits
17
2
1
3, 4
3, 4
7
8
9
10
11
12
13
14
16
15
5
