170 1100 Series DAD and MWD User Manual
10 Control Module Screens
Major keys on the Agilent 1100 Control Module
Ta b le 3 0
ESC Return to previous screen and scroll through top layer views (Analysis, Settings)
m Open context sensitive menus
iInformation/help
Enter Store changed parameters or execute the choice from a pull-down menu
On/Off Switch on lamp(s)
Start Start a run
Plot View the chromatogram
Views Change between view of analysis - status - system screens
NOTE
The screens shown on the next pages are based on the following firmware revisions:
Minimum G1315C DAD and G1365C MWD firmware revision B01.01.
Minimum Control Module firmware revision B.04.01 (G1323B).
Minimum LC Module firmware revision A.06.01.
NOTE
In case the control module’s display seems to be frozen (hang-up due to a communication
problem on the CAN bus, unplug the control module from the LC module and reconnect.
