16 1100 Series DAD and MWD User Manual
1 Site Requirements and Specifications
Performance Specifications
Table 2 Performance Specifications Agilent 1100 Series DAD and MWD
Type Specification Comments
Detection type 1024-element photodiode array
Light source Deuterium and tungsten lamps The UV-lamp is equipped with I.D. tag
that holds lamp typical information.
Wavelength range 190 – 950 nm
Short term noise (ASTM)
Single and
Multi-Wavelength
±1×10
-5
AU at 254 and 750 nm See note on page 17
Drift 2 × 10
-3
AU/hr at 254 nm See note on page 17
Linear absorbance range > 2 AU (upper limit) See note on page 17
Wavelength accuracy ± 1 nm Self-calibration with deuterium lines,
verification with holmium oxide filter
Wavelength bunching 1 – 400 nm Programmable in steps of 1 nm
Slit width 1, 2, 4 , 8, 16 nm Programmable slit
Diode width < 1 nm
Flow cells Standard: 13 µl volume, 10 mm cell path length
and 120 bar (1760 psi) pressure maximum
Semi-Micro: 5 µl volume, 6 mm cell path length
and 120 bar (1760 psi) pressure maximum
High pressure: 1.7 µl volume, 6 mm cell path
length and 400 bar (5880 psi) pressure maximum
500 nano: 0.5 µl volume, 10 mm cell path length
and 50 bar (725 psi) pressure maximum
80 nano: 0.5 µl volume, 10 mm cell path length and
50 bar (725 psi) pressure maximum
See “Optimization Overview” on
page 89
All flow cells are equipped with I.D.
tags that hold cell typical information.
Control and data evaluation Agilent ChemStation for LC (32-bit) Revision B.01.03 or above
