166 1100 Series DAD and MWD User Manual
9 Parts and Materials for Maintenance
Accessory Kit
This kit contains some accessories and tools needed for the installation and
repair of the detector.
For item number refer to Figure 76 and Figure 77.
Table 29 Accessory Kit Parts
Item Description Part Number
Accessory kit G1315-68705
Corrugated tubing (to waste), re-order 5 m 5062-2463
1 Teflon Tubing flexible i.d. 0.8 mm (flow cell to waste),
re-order 5 m
5062-2462
2 Fitting male PEEK, Qty=1 0100-1516
3 Capillary column – detector 380 mm lg, 0.17 i.d. includes items
4, 5 and 6 (not assembled)
G1315-87311
4 Ferrule front 1/16" SST, qty=2, re-order pack of 10 5180-4108
*
* or kit 5062-2418 1/16" Fittings and Ferrules (front/back) 10/PK
5 Ferrule back 1/16" SST, qty=2, re-order pack of 10 5180-4114
*
6 Fitting 1/16" SST, qty=2, re-order pack of 10 5061-3303
*
Hex key set 1–5mm 8710-0641
Wrench open end 1/4 – 5/16 inch 8710-0510
Wrench open end 4 mm 8710-1534
ESD wrist strap 9300-1408
