1100 Series DAD and MWD User Manual 165
Parts and Materials for Maintenance 9
Table 28 lists the specific parts for the 80 nl flow cell.
Table 28 Specific 80 nl Flow Cell Parts
Item Description Part Number
80 nl Flow Cell Kit G1315-68716
1 PEEK coated fused silica capillary Inlet (50 µm)
pre-mounted to cell, includes
Inlet capillary, 400 mm long, 50 µm i.d. with pre-fixed ferrules (#4) and
fittings (#3), plus one PEEK Fitting FT (#5)
G1315-87323
2 PEEK coated fused silica capillary Outlet (50 µm)
pre-mounted to cell, includes
Outlet capillary, 120 mm long, 50 µm i.d. with pre-fixed ferrules (#4) and
fitting (#3), plus one PEEK Fitting FT (#5)
G1315-87328
1 PEEK coated fused silica capillary Inlet (25 µm)
alternative, includes
Inlet capillary, 200 mm long, 25 µm i.d. with pre-fixed ferrules (#4) and
fittings (#3), plus one PEEK Fitting FT (#5)
G1315-87313
2 PEEK coated fused silica capillary Outlet (25 µm)
alternative, includes
Outlet capillary, 600 mm long, 25 µm i.d. with pre-fixed ferrules (#4) and
fitting (#3), plus one PEEK Fitting FT (#5)
G1315-87318
11 Cell Housing (80 nl) G1315-27704
12 Cell Seal Assembly (80 nl) G1315-42301
13 Quartz Body (80 nl) G1315-80002
Sealing Kit 80 nl cell, includes items #10, #12 (QTY=2), #7 (QTY=5)and
Lite Touch Sleeves (QTY=5)
G1315-68725
