Agilent Technologies 1100 Series User Manual

164 1100 Series DAD and MWD User Manual
9 Parts and Materials for Maintenance
Table 27 lists the specific parts for the 500 nl flow cell.
Table 27 Specific 500 nl Flow Cell Parts
Item Description Part Number
500 nl Flow Cell Kit G1315-68724
1 PEEK coated fused silica capillary Inlet (100 µm)
pre-mounted to cell, includes
Inlet capillary, 300 mm long, 100 µm i.d. with pre-fixed ferrules (#4) and
fittings (#3), plus one PEEK Fitting FT (#5)
G1315-87333
2 PEEK coated fused silica capillary Outlet (100 µm)
pre-mounted to cell, includes
Outlet capillary, 120 mm long, 100 µm i.d. with pre-fixed ferrules (#4)
and fitting (#3), plus one PEEK Fitting FT (#5)
G1315-87338
1 PEEK coated fused silica capillary Inlet (50 µm)
alternative, includes
Inlet capillary, 400 mm long, 50 µm i.d. with pre-fixed ferrules (#4) and
fittings (#3), plus one PEEK Fitting FT (#5)
G1315-87323
2 PEEK coated fused silica capillary Outlet (50 µm),
alternative, includes
Outlet capillary, 120 mm long, 50 µm i.d. with pre-fixed ferrules (#4) and
fitting (#3), plus one PEEK Fitting FT (#5)
G1315-87328
1 PEEK coated fused silica capillary Inlet (50 µm)
for earlier 500 nl version kits, includes
Inlet capillary, 400 mm long, 50 µm i.d.
with pre-fixed ferrules (#4) and fittings (#3), plus one PEEK Fitting FT
(#5)
G1315-87323
2 PEEK coated fused silica capillary Outlet (75 µm)
for earlier 500 nl version kits, includes
Outlet capillary, 700 mm long, 75 µm i.d. with pre-fixed ferrules (#4) and
fitting (#3), plus one PEEK Fitting FT (#5)
G1315-68708
11 Cell Housing (500 nl) G1315-27703
12 Cell Seal Assembly (500 nl) G1315-87101
13 Quartz Body (500 nl) G1315-80001
Sealing Kit, includes items #10, #12 (QTY=2) and #7 (QTY=5) G1315-68715
