1100 Series DAD and MWD User Manual 23

Installing the Detector 2

Figure 2 Recommended Stack Configuration (Rear View)

LAN

to LC

ChemStation

Analog

signal to

recorder

AC power

Remote cable

CAN Bus cable

AC power
