Agilent Technologies 1260 Infinity G1315D User Manual

Agilent 1260 Infinity DAD and MWD User Manual 75
Using the Detector
4
Setting up an Analysis
The Online Plot (Figure 21 on page 75) shows both, the pump pressure and
the detector absorbance signals. Pressing Adjust the signals can be reset to
the offset value and Balance would do a balance on the detector.
Figure 21 Online Plot Window
13 If both baselines are stable, set the Y-range for the detector signal to
100 mAU.
3XPSSUHVVXUHVLJQDO
'$'DEVRUEDQFHVLJQDO
NOTE
If you start with a new UV-lamp for the first time, the lamp may show initial drift for some
time (burn-in effect).
