52 Agilent 7890B Installation
1 Installing the GC
GC / MS / Agilent data system / ALS
Additional cabling configurations
For additional cabling configurations, see Appendix B, “Cabling
Diagrams and Remote Start/Stop."
LAN switch or hub
1. LAN cable
8121-0940
GC ComputerMSD
2. APG Remote Cable,
G1530-60930
1. LAN cable
8121-0940
1. LAN cable
8121-0940
Tabl e 9 Cables for a typical GC/MSD or GC/MS system
Number Part number and description
1 G1530-60930, 2-m APG remote cable, 9-pin male/9-pin male
2 8121-0940, Cable, LAN, 25 foot
