The 7890B GC
Figure 1 Front of the 7890B GC
Figure 2 Back of the 7890B GC
Inlets
Oven
Detectors
Operating panel (display,
status indicators, and
keyboard)
Power switch
Detector top
cover
Oven exhaust vent
Inlet vents
Gas supply connections
Electronic cable
connections
Oven cooling intake
Power connection
