Cabling Diagrams and Remote Start/Stop B
Agilent 7890B Installation 91
BCD cable, G1530-61100
The BCD cable connector has eight passive inputs that sense
total binary-coded decimal levels. The pin assignments for this
connector are listed in Table 12.
Tabl e 1 3 BCD cable connections
Connector 1 Pin Connector 2 Pin Ribbon Cable Wire Color
1Brown
2Red
13Orange
4Yellow
5 Green
6Blue
7Violet
8Gray
9White
2, 8 10 Black
11 Brown
612Red
13 Orange
514Yellow
15 Green
416Blue
2
8
1
6
1
26
