5 Maintenance and Troubleshooting
850-DS Operator’s Manual 95
2 Internal side levers hold the roll in place. Since it is empty or nearly empty, use
your fingers to pull out the small roll or core.
Figure 52. Removing the Thermal Paper Roll
Inserting a Thermal Paper Roll
The empty core is disposable. Each new roll includes a cardboard
core. New rolls may be ordered using part number 12-9988 (10
rolls) or 12-9989 (100 rolls).
Only a 58 mm wide x 25 meter (maximum) thermal printer paper
roll with a 13 mm core size can be used in the panel-mount printer.
