5-5
Service
Recommended Test Equipment
Pulse/Function
Generator
Frequency: 10 MHz
Duty cycle: 50%
Output: TTL square wave
8116A Pulse Modulation On/Off Ratio
Pulse Modulation Rise Time
(P)
(P)
RF Mixer Freq. range (RF and LO ports):
1 MHz to 2800 MHz
Freq. range (IF port): 1 MHz to 2000 MHz
Maximum input (LO port): +26 dBM
M/A Com Inc.
MDC-174
FM Accuracy
FM Distortion
Phase Modulation Distortion
Residual FM
(P)
(P)
(P)
(P)
RF Mixer
a
Freq. range (RF and LO ports):
500 MHz to 900 MHz
Freq. range (IF port): 10 MHz to 2000
MHz
Maximum input (LO port): +24 dBM
M/A Com Inc.
MDC-164
FM Accuracy
FM Distortion
Phase Modulation Distortion
Residual FM
(P)
(P)
(P)
(P)
RF Spectrum
Analyzer
Freq. range: 1 MHz to 4000 MHz
Relative level accuracy (harmonic and
spurious measurements): ±2 dB
1 Hz digital resolution BW filter (required
for power accuracy)
Displayed average noise:
100 kHz: −110 dBm
1 MHz to 10 MHz: −130 dBm
10 MHz to 4 GHz: −134 dBM
RF Input VSWR: 1:1.5
External timebase input
8563E Power Level Accuracy
Harmonics
Spurious
Pulse Modulation On/.Off Ratio
Time Base DAC
HF Power Level Accuracy
LF Power Level Accuracy
(P)
(P)
(P)
(P)
(A)
(A)
(A)
Sensor Module No Substitute 11722A RF Level Accuracy (P)
Synthesized
Signal Generator
Freq. range: 11.5 to 1500 MHz
Output level: +16 dBm
Meets 8663A single-sideband phase noise
specifications
8663A FM Accuracy
FM Distortion
Phase Modulation Distortion
Residual FM
(P)
(P)
(P)
(P)
Universal
Counter (Low
Frequency)
b
Freq. accuracy: ±2 millihertz at 1600 Hz 5334B
Option 010
Pager Encoder Timebase
Accuracy
Pager Encoder Timebase Freq
(P)
(A)
Vector Signal
Analyzer
FSK Deviation Accuracy:
±10 Hz at 4.8 kHz deviation
89441A FSK Deviation Accuracy
FSK Deviation
Filter Path
(P)
(A)
(A)
a. Required for testing 8648B/D only.
b. For use in testing 8648A Option 1EP only.
Table 5-1. Recommended Test Equipment
Instrument Critical Specifications Recommended
Model
Use
Performance Test - (P)
Adjustment - (A)
Supp. Verification Test - (V)
