Agilent Technologies 8648A

8-118
Performance Tests
8648C Test Record
NOTE If the automated Power Level Accuracy performance test is performed, the
RF Level Accuracy performance test is not required.
NOTE If the automated Power Level Accuracy performance test is performed, the
Table 8-63. RF Level Accuracy Performance Test - Part 2
Frequency
(MHz)
Amplitude
(dBm)
Limits (dBm)
Uncertainty
(±dB)Lower Measured Upper
2000 13 12 14 0.15
10 9 11 0.15
43 50.15
−5.9 −6.9 −4.9 0.15
−15.9 −16.9 −14.9 0.12
2499 13 12 14 0.32
10 9 11 0.32
43 50.32
−5.9 −6.9 −40.32
−15.9 −16.9 −14.9 0.25
3200 13 11.5 14.5 0.46
10 8.5 11.5 0.46
4 2.5 5.5 0.46
−5.9 −7.4 −4.4 0.46
−15.9 −17.4 −14.4 0.41
