1-118
Making Measurements
Using Test Sequencing to Test a Device
This will create the following displayed lists:
Start of Sequence 
LOOP COUNTER 
7 x1 
INTERNAL DISK 
DATA ONLY 
ON 
DO SEQUENCE 
SEQUENCE 2
Start of Sequence 
FILE NAME 
DT[LOOP] 
PLOT NAME 
PL[LOOP] 
SINGLE 
SAVE FILE 0 
PLOT 
DECR LOOP COUNTER 
IF LOOP COUNTER <> 0 THEN DO 
SEQUENCE 2
Sequence 1 initializes the loop counter and calls sequence 2. Sequence 2 repeats until the loop counter
reaches 0. For each loop, it takes a single sweep, saves the data file and plots the display.
• The data file names generated by this sequence will be:
DT00007.D1
through
DT000001.D1
• The plot file names generated by this sequence will be:
PL00007.FP
through
PL00001.FP
To run the sequence, press:
Copy
PLOT
Seq
SPECIAL FUNCTIONS
DECISION MAKING
DECR LOOP COUNTER
IF LOOP COUNTER 0
SEQUENCE 2 SEQ 2
Seq
DONE SEQ MODIFY
Preset
SEQUENCE 1 SEQ 1
