Making Mixer Measurements
Fixed IF Mixer Measurements
Sequence 2 Setup
The following sequence makes a series of measurements until all 26 CW measurements are made and the
loop counter value is equal to zero. This sequence includes:
•taking data
• incrementing the source frequencies
• decrementing the loop counter
• labeling the screen
1. Press the following keys on the analyzer to create sequence 2:
NOTE To enter the following sequence commands that require titling, an external keyboard may be
used for convenience.
Tak in g D ata
Incrementing the Source Frequencies
Input as title: FREQ:CW UP
Decrementing the Loop Counter
Labeling the Screen
Input as title: MEASUREMENT COMPLETED
Seq
DONE SEQ MODIFY
Seq
NEW SEQ/MODIFY SEQ
SEQUENCE 2 SEQ2
Seq
SPECIAL FUNCTIONS
WAIT x
.1
x1
Sweep Setup
TRIGGER MENU
MANUAL TRG ON POINT
Display
MORE
TITLE
ERASE TITLE
DONE
Seq
SPECIAL FUNCTIONS
PERIPHERAL GPIB ADDR
19
x1
TITLE TO PERIPHERAL
PERIPHERAL GPIB ADDR
21
x1
TITLE TO PERIPHERAL
DECISION MAKING
DECR LOOP COUNTER
IF LOOP COUNTER<>0
SEQUENCE 2 SEQ2
Display
MORE
TITLE
ERASE TITLE
DONE
Seq
DONE SEQ MODIFY
