7- 87
Operating Concepts
Differences between 8753 Network Analyzers
Differences between 8753 Network Analyzers
Tab le 7-5 Comparing the 8753A/B/C/D
Feature 8753A 8753B 8753C 8753D 8753D
Opt. 011
Fully integrated measurement system
(built-in test set)
No No No Yes No
Test port power range (dBm)
a
a. For this network analyzer, the feature is dependent on the test set being used.
a
a
+10 to
85
a
Auto/manual power range selecting No No No Yes No
Port power coupling/uncoupling No No No Yes No
Internal disk drive No No No Yes Yes
Precision frequency reference (Option 1D5) No No No Yes Yes
Frequency range - low end (in kHz) 300 300 300 30
30/300
b
b. 300 kHz to 3 GHz without Option 006; 30 kHz to 6 GHz, with Option 006.
Ext. frequency range to 6 GHz (Option 006) No Ye s Ye s Yes Yes
75 system impedance (Option 075)
a
a
a
Yes
a
TRL*/LRM* correction No No No Yes Yes
Power meter calibration No Yes Ye s Ye s Yes
Interpolated error correction No Yes Ye s Yes Yes
Maximum error corrected measurement points 801 1601 1601 1601 1601
Segmented error correction in frequency list mode No No Ye s Yes Yes
Color CRT No No Ye s Yes Yes
Tes t s equ en cin g No Yes Ye s Ye s Yes
Automatic sweep time No Yes Ye s Yes Yes
External source capability No Yes Ye s Ye s Yes
Tuned receiver mode No Yes Ye s Ye s Yes
Printer/plotter buffer No Yes Ye s Ye s Yes
Harmonic measurements (Option 002) No Yes Ye s Yes Yes
Frequency offset mode (mixer measurements) No Yes Ye s Yes Yes
dc bias to test device
a
a
a
Yes
a
Interfaces: RS-232, parallel, and DIN keyboard No No No Yes Yes
User-defined preset No No No Yes Yes
Non-volatile memory (in Kbytes) 16 16 16 512 512
Dynamic range: 30 kHz 3 GHz 100 dB 100 dB 100 dB
110 dB
c
c. 90 dB from 30 kHz to 50 kHz; 100 dB from 300 kHz to 16 MHz.
100 dB
Dynamic range: 3 GHz 6 GHz N/A 80 dB 80 dB 105 dB 110 dB
Real time clock No No No Yes Yes
