Operating Concepts
Differences between 8753 Network Analyzers
Tab le 7-6 Comparing the 8753D/E/ES
Feature 8753D
8753E 8753ES
Fully integrated measurement system (built-in test set) Ye s Ye s Yes
Test port power range (dBm) +10 to 85 +10 to 85 +10 to 85
Auto/manual power range selecting Ye s Yes Yes
Port power coupling/uncoupling Ye s Yes Yes
Internal disk drive Ye s Yes Yes
Flash EPROM No Yes Yes
Precision frequency reference (Option 1D5) Ye s Ye s Yes
Frequency range - low end (in kHz) 30 30 30
Ext. frequency range to 6 GHz (Option 006) Ye s Yes Yes
75 system impedance (Option 075) Ye s Ye s Yes
TRL*/LRM* correction Ye s Yes Yes
Power meter calibration Ye s Ye s Yes
Interpolated error correction Ye s Yes Yes
Enhanced response calibration No Ye s Yes
Maximum error corrected measurement points 1601 1601 1601
Configurable test set (Option 014) No Yes Yes
Segmented error correction in frequency list mode Ye s Yes Yes
Swept list frequency sweep No Yes Yes
Sweep speed (201 points, one-port cal, ms) 200 77 70
Sweep speed (201 points, full 2-port cal) 510 145 121
Speed in time domain transform 350 46 42
Data I/O speed (GPIB) (ms, internal binary) 35 11 16
Four parameter display No Ye s Yes
Markers/display channel 4 5 5
Total viewable markers at any time 8 20 20
Color display Ye s Yes Yes
Flat panel LCD No Yes Yes
VGA output No Yes Yes
Delete display (Option 1DT) No Yes No
Tes t s equ en cin g Ye s Yes Yes
Automatic sweep time Ye s Yes Yes
External source capability Ye s Yes Yes
Tuned receiver mode Ye s Yes Yes
Printer/plotter buffer Ye s Yes Yes
Harmonic measurements (Option 002) Ye s Yes Yes
Frequency offset mode (mixer measurements) Ye s Ye s Yes
dc bias to test device Ye s Ye s Yes
