4-42
Printing, Plotting, and Saving Measurement Results
Saving Measurement Results
Saving in Textual (CSV) Form
Textual measurement results can be saved in a comma-separated value (CSV) format and imported into a
spreadsheet application. Additional information is also saved as a preamble to the measurement results.
The saved information includes:
• Network analyzer model number and firmware version
• Date the file was saved
• Type of measurement being done
• Start and stop frequencies
•Sweep time
•Port power
•IF bandwidth
• Channel number
• Number of points
•Format
• The frequency (or time) and the real and imaginary measurement values for each of points measured
1. Press .
2. Make sure that is displayed.
3. Make sure that is underlined. If it is not underlined, press the softkey so that
TEXT is underlined.
4. Insert a 3.5-inch floppy disk in the network analyzer’s disk drive.
5. Press to save the display information as text in the CSV format.
The text file may be retrieved from the floppy disk on personal computer and can be imported into an
application that accepts text in the comma-separated value format, such as a spreadsheet.
