Agilent Technologies 8720ES User Manual

1- 117
Making Measurements
Using Test Sequencing to Test a Device
This will create a displayed list as shown:
SEQUENCE LOOP 2
Start of Sequence
Trans:FWD S21 (B/R)
SCALE/DIV
AUTO SCALE
MKR Fctn
SEARCH MAX
DECR LOOP COUNTER
IF LOOP COUNTER <> 0 THEN DO
SEQUENCE 2
To run the loop sequence, press:
Generating Files in a Loop Counter Example Sequence
This example shows how to increment the names of files that are generated by a sequence with a loop
structure.
DECR LOOP COUNTER
IF LOOP COUNTER 0
SEQUENCE 2 SEQ2
Seq
DONE SEQ MODIFY
Preset
SEQUENCE 1 SEQ1
Seq
NEW SEQ/MODIFY SEQ
SEQUENCE 1 SEQ 1
SPECIAL FUNCTIONS
DECISION MAKING
LOOP COUNTER
7
x1
Save/Recall
SELECT DISK
INTERNAL DISK
RETURN
DEFINE DISK-SAVE
DATA ONLY ON
Local
SET ADDRESSES
PLOTTER PORT
DISK
Seq
DO SEQUENCE
SEQUENCE 2
DONE SEQ MODIFY
NEW SEQ/MODIFY SEQ
SEQUENCE 2 SEQ 2
Save/Recall
FILE UTILITIES
SEQUENCE FILE NAMING
FILE NAME FILE0
ERASE TITLE
D
T
LOOP COUNTER
DONE
PLOT NAME PLOTFILE
ERASE TITLE
P
L
LOOP COUNTER
DONE
RETURN
Sweep Setup
TRIGGER MENU
SINGLE
Save/Recall
SAVE STATE
