Agilent Technologies 8720ES User Manual

1-122
Making Measurements
Single Connection Multiple Measurement Configuration (Option 014 Only)
of how to setup the analyzer.
Press the following key sequence:
Rotate the knob on the front panel and select the following:
Rotate the knob on the front panel and select the following:



Preset the instrument. Display softkeys should show .
Sequence program example for EXT: (as displayed on the analyzer)
Start of Sequence 
TESTSET I/O FWD 
6 
x1 
TESTSET I/O REV 
6 
x1 
1972 empty bytes available.
GPIB Commands
TSTIOFWD7; TSTIOFWD6; TSTIOREV7; TSTIOREV6;
Seq
NEW SEQ/MODIFY SEQ
SEQUENCE 1 SEQ1
TTL I/O
TTL OUT
TESTSET I/O FWD
6
x1
TESTSET I/O REV
6
x1
RETURN
RETURN
DONE SEQ MODIFY
MORE
TITLE SEQUENCE
SEQUENCE 1 SEQ1
ERASE TITLE
E
SELECT LETTER
X
SELECT LETTER
T
SELECT LETTER
DONE
RETURN
NEW SEQ/MODIFY SEQ
SEQUENCE 2 SEQ2
TTL I/O
TTL OUT
TESTSET I/O FWD
7
x1
TESTSET I/O REV
7
x1
RETURN
RETURN
DONE SEQ MODIFY
MORE
TITLE SEQUENCE
SEQUENCE 1 SEQ1
ERASE TITLE
S
SELECT LETTER
T
SELECT LETTER
D
SELECT LETTER
DONE
RETURN
SEQUENCE 1 EXT
SEQUENCE 2 STD
