2- 27
Making Mixer Measurements
Fixed IF Mixer Measurements
the rear panel of the analyzer (a BNC tee must be used).
NOTE If the 10 MHz reference signals of the external sources are connected together, then it will
only be necessary to connect one reference signal from one of the sources to the EXT REF
connector of the analyzer.
Figure 2-21 Connections for a Response Calibration
NOTE To enter the following sequence commands that require titling, an external keyboard may be
used for convenience.
4. Press the following keys on the analyzer to create sequence 1:
Presetting the Instrument
(Select the preset state.)
