Agilent Technologies 8720ES User Manual

2- 29
Making Mixer Measurements
Fixed IF Mixer Measurements
Initializing a Loop Counter Value to 26
Addressing and Configuring the Two Sources
Input as title: FREQ:MODE CW;CW 500MHZ;:FREQ:CW:STEP 100MHZ
Input as title: POW:LEV 13DBM
Input as title: FREQ:MODE CW;CW 600MHZ;:FREQ:CW:STEP 100MHZ
Calling the Next Measurement Sequence
Press and the analyzer will display the
following sequence commands:
SEQUENCE SEQ1
Start of Sequence
RECALL PRST STATE
SYSTEM CONTROLLER
Seq
SPECIAL FUNCTIONS
DECISION MAKING
LOOP COUNTER
26
x1
Scale Ref
2
x1
REFERENCE POSITION
0
x1
REFERENCE VALUE
20
x1
Sweep Setup
TRIGGER MENU
MANUAL TRG ON POINT
Display
MORE
TITLE
ERASE TITLE
DONE
Seq
SPECIAL FUNCTIONS
PERIPHERAL GPIB ADDR
19
x1
TITLE TO PERIPHERAL
Display
MORE
TITLE
ERASE TITLE
DONE
Seq
SPECIAL FUNCTIONS
PERIPHERAL GPIB ADDR
21
x1
TITLE TO PERIPHERAL
Display
MORE
TITLE
ERASE TITLE
DONE
Seq
SPECIAL FUNCTIONS
PERIPHERAL GPIB ADDR
21
x1
TITLE TO PERIPHERAL
Seq
DO SEQUENCE
SEQUENCE 2 SEQ2
Seq
DONE SEQ MODIFY
Seq
NEW SEQ/MODIFY SEQ
SEQUENCE 1 SEQ 1
