Agilent Technologies 8720ES User Manual

1- 71
Making Measurements
Using the Swept List Mode to Test a Device
4. To maximize the dynamic range in the stopband (increasing the incident power and narrowing the IF
bandwidth), press
until ON is selected
until ON is selected
Set Up the Passband Parameters
5. To set up the segment for the passband, press
6. To specify a lower power level and a wider IF bandwidth for the passband, press
Set Up the Upper Stopband Parameters
7. To set up the segment for the upper stopband, press
ADD
START
650
M/
STOP
880
M/
NUMBER of POINTS
51
x1
MORE
LIST POWER ON off
SEGMENT POWER
10
x1
LIST IF BW ON off
SEGMENT IF BW
1000
x1
RETURN
DONE
ADD
CENTER
900
M/
SPAN
40
M/
STEP SIZE
.2
M/
MORE
SEGMENT POWER
10
x1
SEGMENT IF BW
3700
x1
RETURN
DONE
ADD
START
920
M/
STOP
1150
M/
NUMBER of POINTS
51
x1
