Agilent Technologies B1500A Self-Paced Training Manual

4-9
To Modify Test Definition
Add local variable (ex: Yes and No) for Message box
Test Definition editor
Variables Yes and
No are used in the
message box.
On the Test Contents tab screen, add program lines in the test execution flow. In this section, the
following lines are inserted between the Vth_gmmax line and the Auto Analysis line.
Message
IF Yes=0
END
END IF
This will open the message box after the measurement is completed and before the auto analysis
is performed.
At first, the variables used in the message box. For example, Yes and No variables are defined.
Click Local Variables Definition line to display the local variable list shown above. And define the
variables.
Example:
Name=Yes, Value=0, Description=User response
Name=No, Value=0, Description=User response
