Agilent Technologies E4448A Service Guide

Chapter 10 231
Replaceable Parts Lists and Locations
Replaceable Parts
Table 10-2 Mechanical Parts
Description Part Number E4440A E4443A E4445A E4446A E4447A E4448A
Dress Panel, rear E4440-00059 X X X X X X
Disk Drive Board E4406-60014 X X X X X X
Disk Drive Mount E4406-40006 X X X X X X
L-bracket, RF Main
E4440-00001 X X X
E4446-00003 X X X
RF Frame E4440-20165 X X X X X X
Bracket,
Electronic Attenuator
(Option B7J)
E4440-00024 X X X X X X
Bracket,
Bandpass Filter
E4440-00022 X X X X X X
Bracket, RF Micro
E4440-00002 X X X
E4446-00001 X X X
Bracket,
RF Attenuators
E4440-00017 X X X
E4446-00002 X X X
Lid, A18 YTO E4440-00019 X X X X X X
Shield, A18 YTO E4440-00018 X X X X X X
Screw,
M3 x 0.58 MM long
0515-0372 X X X X X X
Grommet, A18 YTO
(2 each)
0400-0333 X X X X X X
Shoulder Washers,
A18 YTO (2 each)
5022-0179 X X X X X X
Screw, A18 YTO Shield
(2 each)
0515-0665 X X X X X X
Cable clip for
A15 Attenuator
ribbon cable
1400-0611 X X X X X X
Standoffs,
Memory boards
0380-4163 X X X X X X
Screwlock, GPIB
.327 x 6-32
0380-0644 X X X X X X
Washer, lock for GPIB
Screwlock, 0.194 ID
2190-0577 X X X X X X
