24 Chapter 1
Overview
Service Equipment You Will Need
Required Test Equipment List
The following table identifies the equipment recommended for
troubleshooting, adjusting, and verifying the performance of the
instrument. Only the recommended and alternate equipment is
compatible with the performance verification testing. Some tests can
use various models of a particular equipment type. The “Recommended
Agilent Model” is the preferred equipment. However, the “Alternative
Agilent Model” is an acceptable substitute.
Table 1-3 Required Test Equipment for PSA Series
Instrument Critical Specifications Recommended
Agilent Model
Number
Alternative
Agilent Model
Number
Use
a
Signal Sources
RF Source 1
(for Option B7J)
Not required for Agilent
Recommended test plan
variant)
Ability to create 64 tones across a 5 MHz span
synchronously, 5 MHz to 10 MHz
Resolution: 0.02
E4433B
(Option UND)
E4437B
(Option UND
FW datecode
≥ B.02.24)
P
RF Source 2 Frequency: 50 MHz to 1.0 GHz
Harmonics: < -30 dBc ≤ +13 dBm
Spectral Purity SSB Phase Noise @ 1 GHz:
−112 dBc at 100 Hz offset
−121 dBc at 1 kHz offset
−131 dBc at 10 kHz offset
VSWR: < 1.5:1
E8257D
b
PSG
cd
8663A
A, P, T
RF Source 3
Frequency: 100 kHz to 3.0 GHz
Spectral Purity: SSB Phase Noise @ 1 GHz:
−145 dBc at 100 kHz offset
−158 dBc at 1 MHz offset
−160 dBc at 6 MHz offset
−160 dBc at 10 MHz offset
Harmonics: -30 dBc @ ≤ +10 dBm output
E8257D
b
PSG
cd
8665A/B
(Option 004)
(for Freq Resp
below 3.6 GHz
test and Phase
Noise > 30 kHz
test only)
8665A/B
(std)
P
Microwave Source 1
(for E4440A, 43A, 45A)
Frequency: 10 MHz to 26.5 GHz
Frequency Resolution: 1 Hz
Harmonic level: < -30 dBc
Amplitude range: -20dBm to +13
Amplitude resolution: 0.02
VSWR: < 20 GHz: 1.6:1
≤ 31 GHz: 1.8:1
E8257D
b 83630A/B
83640A/B
83650A/B
(Option 001, 008)
(One sweeper
requires Option
001 for PSA
Option 110
testing)
PSG
cd
A, P, T
