Agilent Technologies E4448A Service Guide

240 Chapter 10
Replaceable Parts Lists and Locations
Replaceable Parts
W43 Cable, semi-rigid, AT1
to FELOMA J2 (SBTX)
E4446-20049 X X X
W44 Cable (9), coax,
IF IN from front-panel to
A10 3rd Converter J3
(Option AYZ)
E4440-60374 X X X X
W45 Cable, semi-rigid,
LO OUT from front-panel to
W46 (Option AYZ)
E4440-20095 X X X X
W46 Cable, semi-rigid,
LO OUT extension cable
from A21 SLODA 1st LO
OUT to W45.
(Option AYZ, for PSA ≤ 26.5
GHz)
E4440-20087 X
W46 Cable, semi-rigid, LO
OUT extension cable from
A21 FELOMA LO OUT to
W45.
(Option AYZ and 123,
for PSA > 26.5 GHz)
E4446-20035 X X X
W47 Cable (97), coax,
Preselector Tune Out A13
Front End Driver to Rear
Panel
8121-0153 X X X X X X
W48 Cable, semi-rigid,
FL1 Low Pass Filter to
A22 Preamp Assy.
(Option 1DS)
E4440-20072 X X X
E4446-20038 X X X
W49 Cable, ribbon, Preamp
control from A13 Front End
Driver to A22 Preamp Assy.
(Option 1DS)
E4440-60073 X X X X X X
W50 Cable, semi-rigid,
Preamp Out from A22
Preamp to Lowband
(Option 1DS)
E4440-20079 X X X X X X
W51 Cable, semi-rigid, A19
SBTX/RYTHM out to A27
Electronic Attenuator
(Option B7J)
E4440-20110 X X X
E4446-20039 X X X
Table 10-3 Cables
a
Description Part
Number
E4440A E4443A E4445A E4446A E4447A E4448A
