Chapter 12 427
Post-Repair Procedures
Configuring a Replacement Flash Memory Assembly
a. Press System, More until the Licensing softkey is visible. Press
Licensing and Option. This will activate the alpha editor menu. Use
the alpha editor to enter the upper case option designator. Press
Enter.
b. Press
License Key. The license key number is a hexadecimal number
that will require the entry of both letters and numbers. Use the
alpha editor to enter the letters and the front panel numeric
keyboard to enter the numbers. You will see your entry in the active
function area. When you have completed entering the license key
number, press
Enter.
NOTE It is very important to enter the number accurately. Since it is a
hexadecimal, the letter “O” can not be present, only zeros are used in
the license key number.
c. After you have entered the option designator and the license key
number, press
Activate License.
Step 4: Loading Firmware for Measurement Options (if needed)
a. Refer to Chapter 13 , “Firmware Upgrades.” Since the replacement
Flash board does not come preloaded with all possible options, you
must load the option FW at this time. It may be necessary to enter
an IP address when down loading the firmware. See step 5.
b. The options will now be available. Press
System, Show System to
assure the options have been loaded.
Step 5: Entering the IP Address and Host Name
a. To enter the IP address, press
System, Config I/O, IP Address. Type in
the address and press
Enter.
b. To enter the Host Name, press
Host Name. Type in the host name and
press
Enter.
c. To enter the Subnet Mask, press
Subnet Mask. Type in the subnet
mask, then press
Enter.
d. To enter the Default Gateway, press
Default Gateway. Type in the
default gateway, then press
Enter.
e. The Flash configuration is now complete.
