136 Agilent 1260 Infinity RID User Manual
9 Maintenance
Correcting Leaks
Correcting Leaks
1 Remove the front cover.
2 Open the service door.
3 Use tissue to dry the leak sensor area and the leak pan.
4 Observe the interface ports and the valve area for leaks and correct, if
required.
5 Close the service door.
6 Replace the front cover.
Figure 36 Observing for Leaks
When If a leakage has occurred in the valve area or at the capillary connections
Tools required Tissue
Two 1/4 inch wrenches for capillary connections
HZgk^XZYddg
AZV`hZchdg
KVakZhVcYijW^c\
