Agilent Technologies Infinity 1260 User Manual

54 Agilent 1260 Infinity RID User Manual
3 Installing the Refractive Index Detector
Optimizing the Stack Configuration
Optimizing the Two Stack Configuration
To avoid excessive height of the stack when the autosampler thermostat is
added to the system it is recommended to form two stacks. Some users prefer
the lower height of this arrangement even without the autosampler
thermostat. A slightly longer capillary is required between the pump and
autosampler. (See Figure 18 on page 54 and Figure 19 on page 55).
Figure 18 Recommended Two Stack Configuration for 1260 (Front View)
>chiVciE^adi
9ZiZXidg
8dajbcXdbeVgibZci
6jidhVbeaZg
I]ZgbdhiVi[dgi]Z6AH
dei^dcVa
HdakZciXVW^cZi
9Z\VhhZgdei^dcVa
Ejbe
