56 Agilent 1260 Infinity RID User Manual
3 Installing the Refractive Index Detector
Installing the Detector
Installing the Detector
For other cables see “Cable Overview” on page 146
1 Install the LAN interface board in the detector (if required), see “Replacing
the Interface Board” on page 139.
2 Place the detector in the stack or on the bench in a horizontal position.
Parts required Description
Power cord
Hardware required Agilent 1260 Infinity Refractive Index Detector (G1362A)
Preparations • Locate bench space
• Provide power connections
• Unpack the detector
NOTE
The detector is turned on when the line power switch is pressed and the green indicator
lamp is illuminated. The detector is turned off when the line power switch is protruding and
the green light is OFF.
WARNING
Module is partially energized when switched off, as long as the power cord is
plugged in.
Repair work at the module can lead to personal injuries, e.g. shock hazard, when the
cover is opened and the module is connected to power.
➔ Make sure that it is always possible to access the power plug.
➔ Remove the power cable from the instrument before opening the cover.
➔ Do not connect the power cable to the Instrument while the covers are removed.
NOTE
The detector was shipped with default configuration settings. To change these settings see
“Setting the 8-bit Configuration Switch (without On-Board LAN)” on page 33.
