24 Agilent 1260 Infinity RID User Manual
1 Introduction to the Refractive Index Detector
Electrical Connections
Rear View of the Module
Figure 9 Rear View of Detector – Electrical Connections and Label
Serial Number Information
The serial number information on the instrument labels provide the following
information:
NOTE
The GPIB interface has been removed with the introduction of the 1260 Infinity modules.
CCXZZ00000 Format
CC Country of manufacturing (DE Germany)
X Alphabetic character A-Z (used by manufacturing)
ZZ Alpha-numeric code 0-9, A-Z, where each combination
unambiguously denotes a module (there can be more than one
code for the same module)
00000 Serial number
