113
REPLACEMENT OF MAIN COMPONENTS
7) Mount the igniter and 4 ignition coils with the brack-
et by 2 bolts and 2 nuts.
5. Mount the 4 high voltage cables.
6. Mount the spark plugs with a plug wrench. (4 places)
7. Connect the blow-by hose.
8. Connect the air intake hose, the fuel gas hose and
the oil hose to the engine.
Bracket
Bolts
Nuts
Caps
Spark plugs
(4 places)
(4 places)
Blow-by hose
Fuel gas hose
Air intake hose
Oil hose
To Next Page
