146
CONTROL
EEPROM dip switch 2 (Setting can be changed with check code No. 81)
EEPROM dip switch 3 (Setting can be changed with check code No. 82)
EEPROM dip switch 4 (Setting can be changed with check code No. 83)
Pin No. Functions
Factory
default
1
Setting of cool/heat
switching (※3)
OFF : Indoor unit ON : Outdoor unit OFF
2
Master control (※3)
OFF:
Pro-
hibited
ON: Master
collec-
tive
OFF:
Dependent
collective
ON:
Individual
setting
ON
3OFF:OFF:ON:ON:ON
4 －－OFF
5 －－OFF
6 Reserved area (※4) － OFF
7
Outdoor fan high static
pressure mode
OFF : Not available / ON : Available OFF
8
Large indoor unit
connection (※3)
OFF: Disconnected?ON: Connected OFF
Pin No. Functions Factory default
1 －－OFF
2 －－OFF
3 Reserved area (※4) － Depend on models
4 Reserved area (※4) － Depend on models
5 Reserved area (※4) － Depend on models
6 －－OFF
7 －－OFF
8 －－OFF
Pin No. Functions Factory default
1 －－OFF
2 －－OFF
3 Reserved area (※4) － OFF
4 －－OFF
5 Reserved area (※4) － OFF
6 Reserved area (※4) － OFF
7 Reserved area (※4) － OFF
8 －－OFF
