20
Introduction
Figure 3 In control box
Figure 4 2F
ENLARGE
Igniter
DCBL PCB
Transformer 1
Electric leakage breaker
Main PCB
Communication I/F PCB
Power supply PCB
EMC PCB
Cold district PCB
Diode
(unit with drain
heater kit only)
Capacitor
Reactor
Radiator cap
Exhaust port
Engine compartment temperatur
e
sensor
Outside air temperature sensor
Fan motors
Outdoor fans
Outdoor heat exchanger
(front)
Outdoor heat exchanger (rear)
(attached to the 1F top panel)
